zarlcode interface

zarlcode is a full terminal application, not a scrolling log. This page is the map: every screen it can show, what each one is for, and the key that opens it. It’s designed for a wide terminal — at the home form factor (~220–280 columns) you get the two-pane layout below; it degrades gracefully as the window narrows.

The layout

The default screen is four regions:

• Timeline (left / main) — the run transcript: your prompts, the assistant’s streamed replies, tool calls, thinking, sub-agents.
• Cockpit (right sidebar, ~56 cols) — live context, cost, and tool telemetry for the session.
• Composer (bottom) — the input box, 3–8 lines, multi-line aware.
• Status bar (very bottom) — context-sensitive key hints on the left, transient toasts on the right.

The layout is responsive. At ≥160 columns the cockpit sidebar shows; below that it collapses and the timeline goes full-width.

When you launch zarlcode with no flags, an unconfigured installation opens the first-run screen. Press Enter to accept local defaults or Ctrl+S to configure a provider. Once configured, launch opens the usual intro screen: type a task to start fresh or choose a saved session to resume. The overlay shortcuts below activate once you are past the intro and in the main UI. See First run and onboarding for the setup path.

Saved-session rows are ordered with pinned sessions first, then by recent activity. Focus the session list and press / to search, p to pin or unpin, Ctrl+N to rename, or d to permanently delete that local session—including its canonical transcript and saved draft—after confirmation. Rows also summarize message, plan, changed-file, model/agent, and pending-draft state.

Composer text is a debounced, session-local draft in SQLite. If you quit before submitting, resume that session to continue editing; an accepted submission clears the draft, and deleting the session removes it.

Resume requires a valid canonical transcript. If it is missing, empty, or fails integrity validation, zarlcode refuses to resume instead of falling back to compacted model context or showing a partial reconstruction.

The timeline

The timeline is a vertical list of typed items, rendered tail-first so the newest is at the bottom and the view follows the stream live. Item kinds include:

• prompts and assistant turns (streamed markdown),
• tool calls and their results, formatted per tool (a bash command, a file path, a diff),
• thinking blocks — collapsible reasoning,
• groups — per-iteration bundles of tools/edits, collapsed behind a [+] toggle,
• sub-agents — a spawned run nested inline,
• diffs, plans, and notices (e.g. a compaction marker).

These items are projected from a canonical, renderer-independent transcript stored in local SQLite. The transcript—not the current widget tree—is the source used for resume and Markdown export. Model context is stored separately and may be compacted without removing earlier visible timeline events. See Sessions and transcripts. Resuming rebuilds plans, diffs, tool activity/results, and nested sub-agent activity from these records; compactable model context is restored separately for the next provider request.

Press Tab to enter browse mode: the view freezes, arrow keys move the selection item-by-item, and Space/Enter collapse or expand the selected item. Press v to start visual line selection, extend it with ↑/↓, j/k, page keys, or g/G, then press y to copy clean transcript text without ANSI styling or timeline rails. Esc cancels selection first, then Esc again (or i) returns to the live tail. This is how you scroll back through a long run, fold away noisy tool output, copy a useful excerpt, or open a sub-agent to see what it did.

The cockpit and dashboard

The sidebar cockpit is a live readout of the run: provider and model, the context window and compaction threshold, a role-partitioned context gauge (system / user / assistant / tool / free), the last turn’s flow (tokens in/out, iterations, duration, tok/s), session cost with cache savings, and a histogram of the tools used so far.

Press Ctrl+L to expand it into the full-screen dashboard — the same metrics at scale across one to three responsive columns: context composition, sparklines for throughput / cache-hit / cost, and a per-turn history table (with a ↯ marker on turns where compaction fired). Arrow keys and PageUp/PageDown scroll it; Esc or Ctrl+L closes it.

The working set

Press Ctrl+W to see every file the agent has mutated this session, plus the turns that changed them and any tracked background processes. Tab cycles between Files, Turns, and Processes; the detail area shows the selected change or process.

From here, Enter opens the full diff browser for the selected file or turn, o opens the file in your editor, and r rolls the file or turn back to its checkpoint — zarlcode snapshots file state per turn, so a bad edit is undoable without git.

The file viewer

Press Ctrl+F for a full-screen, read-only browser with four tabs (Tab to cycle):

• Files — a directory tree on the left, file preview on the right.
• Skills — the workspace’s discovered skills.
• Agents — the named sub-agent profiles available to agent_spawn.
• Hooks — configured command hooks.

Arrow keys move, Enter descends into a directory (or jumps to a definition’s source), o opens the selected file in your editor, and Esc closes. Open it directly with Ctrl+F. It’s the fastest way to see what the agent can see.

Plan and build mode

Press Shift+Tab to toggle between build mode (the default — full tool surface) and plan mode. In plan mode the UI tint shifts, the agent’s tool surface goes read-only, and it produces a structured, reviewable plan instead of editing. Toggle back to build when the plan looks right. Open the Plan browser with Ctrl+P to review live and saved plans (the latter persist under .zarlcode/plans/).

Models, providers, and themes

• Ctrl+S — open Settings, including the Providers panel for API keys, OAuth, custom OpenAI-compatible endpoints, and other workspace configuration.
• Ctrl+E — open the model picker directly to change the active provider/model pair.
• Ctrl+K — the searchable command palette: a discovery and fallback surface for help, settings, model and theme pickers, session naming, plan and tool-history panes, the file viewer, copying the latest assistant response, and Markdown session export.
• Ctrl+N names or renames the active session; /name <label> does the same.
• Ctrl+Shift+C copies the latest assistant response. /export [path] writes the canonical transcript as Markdown; without a path it uses .zarlcode/exports/ in the current workspace and never overwrites an existing export.
• Settings → interface → notification sounds controls terminal bells: off, completion (the default), or all to also ring as plan steps complete.
• While a turn is active, zarlcode best-effort inhibits operating-system sleep on Linux and macOS; the turn continues normally if inhibition is unavailable.

For first-time provider setup and credential protection, see Providers and credentials.

Sub-agents

When a turn delegates with agent_spawn, launch returns a receipt immediately and the parent can continue independent work. Each child run appears as a collapsible sub-agent item in the timeline, nested under the turn that spawned it — its own prompt, tool calls, and final summary remain independently foldable in browse mode. On supported receiving providers, a child’s completion is delivered directly as input to the parent model at a safe history boundary; no agent_await call is needed just to receive the result. The parent continues with that evidence from the child’s original assignment, not a new user instruction. Use agent_status for an intentional non-blocking snapshot and agent_await for an explicit wait or reread; other receiving providers retain explicit collection. See Sub-agent tasks for the receiving-provider scope. A coordinator fanning out to read-only explore workers reads as a tidy tree rather than a wall of interleaved output; overlapping workspace operations are serialized rather than racing.

Keybinding reference

Key	Action
Enter	submit the prompt
Shift+Enter / Ctrl+J	newline in the composer
↑ / ↓	browse input history (in the composer)
Tab	enter timeline browse mode
v / y	select transcript lines / copy selection in browse mode
Esc	stop the running turn / leave browse / close an overlay
Shift+Tab	toggle plan ⇄ build mode
Ctrl+K	search the command palette
Ctrl+N	name or rename the active session
Ctrl+Shift+C	copy the latest assistant response
Ctrl+L	expand / collapse the context dashboard
Ctrl+F / Ctrl+W	open the file viewer / working set
Ctrl+E / Ctrl+P	open the model picker / plan pane
Ctrl+G	key help
Ctrl+Q	conversation actions
Ctrl+C	stop the running turn; press again when idle to quit

Slash commands work in the composer too: /clear resets the conversation, /help opens key help, /name [label] names the session, and /export [path] writes a Markdown transcript. Press Ctrl+G any time for the full, context-aware list.

Automation

Launch flags, credential subcommands, headless tasks, diagnostics, and upgrade are supported advanced surfaces. See Automation and CLI for the complete reference; normal interactive use starts with zarlcode in the workspace.
