zarlcode interface

zarlcode is a full terminal application, not a scrolling log. This page is the map: every screen it can show, what each one is for, and the key that opens it. It’s designed for a wide terminal — at the home form factor (~220–280 columns) you get the two-pane layout below; it degrades gracefully as the window narrows.

The layout

The default screen is four regions:

• Timeline (left / main) — the run transcript: your prompts, the assistant’s streamed replies, tool calls, thinking, sub-agents.
• Cockpit (right sidebar, ~56 cols) — live context, cost, and tool telemetry for the session.
• Composer (bottom) — the input box, 3–8 lines, multi-line aware.
• Status bar (very bottom) — context-sensitive key hints on the left, transient toasts on the right.

The layout is responsive. At ≥160 columns the cockpit sidebar shows; below that it collapses and the timeline goes full-width, with the run state folded into a compact text strip. Nothing disappears as the window shrinks — it reflows.

When you launch zarlcode with no flags you land on the intro screen: a prompt box and a picker of saved sessions. Type a task and press Enter to start fresh, or pick a prior session to resume. (The overlay shortcuts below only activate once you’re past the intro, in the main UI.)

The timeline

The timeline is a vertical list of typed items, rendered tail-first so the newest is at the bottom and the view follows the stream live. Item kinds include:

• prompts and assistant turns (streamed markdown),
• tool calls and their results, formatted per tool (a bash command, a file path, a diff),
• thinking blocks — collapsible reasoning,
• groups — per-iteration bundles of tools/edits, collapsed behind a [+] toggle,
• sub-agents — a spawned run nested inline,
• diffs, plans, and notices (e.g. a compaction marker).

Press Tab to enter browse mode: the view freezes, arrow keys move the selection item-by-item, and Space/Enter collapse or expand the selected item. Press v to start visual line selection, extend it with ↑/↓, j/k, page keys, or g/G, then press y to copy clean transcript text without ANSI styling or timeline rails. Esc cancels selection first, then Esc again (or i) returns to the live tail. This is how you scroll back through a long run, fold away noisy tool output, copy a useful excerpt, or open a sub-agent to see what it did.

The cockpit and dashboard

The sidebar cockpit is a live readout of the run: provider and model, the context window and compaction threshold, a role-partitioned context gauge (system / user / assistant / tool / free), the last turn’s flow (tokens in/out, iterations, duration, tok/s), session cost with cache savings, and a histogram of the tools used so far.

Press Ctrl+L to expand it into the full-screen dashboard — the same metrics at scale across one to three responsive columns: context composition, sparklines for throughput / cache-hit / cost, and a per-turn history table (with a ↯ marker on turns where compaction fired). Arrow keys and PageUp/PageDown scroll it; Esc or Ctrl+L closes it.

The working set

Press Ctrl+W for the working set — every file the agent has mutated this session, plus the turns that changed them. The left column toggles between a Files view and a Turns view (Tab); the right shows the corresponding diffs.

From here, Enter opens the full diff browser for the selected file or turn, o opens the file in your editor, and r rolls the file or turn back to its checkpoint — zarlcode snapshots file state per turn, so a bad edit is undoable without git.

The file viewer

Press Ctrl+F for a full-screen, read-only file viewer with four tabs (Tab to cycle):

• Files — a directory tree on the left, file preview on the right.
• Skills — the workspace’s discovered skills.
• Agents — the named sub-agent profiles available to agent_spawn.
• Hooks — configured command hooks.

Arrow keys move, Enter descends into a directory (or jumps to a definition’s source), o opens the selected file in your editor, and Esc closes. It’s the fastest way to see what the agent can see.

Plan and build mode

Press Shift+Tab to toggle between build mode (the default — full tool surface) and plan mode. In plan mode the UI tint shifts, the agent’s tool surface goes read-only, and it produces a structured, reviewable plan instead of editing. Toggle back to build when the plan looks right. Ctrl+P opens the plan pane to review live and saved plans (the latter persist under .zarlcode/plans/).

Models, providers, and themes

• Ctrl+E — the model picker: provider tabs across the top (Tab/←/→), a scrollable model list, and a free-text fallback for a model name the list doesn’t have. Selecting re-points the live runner mid-session.
• Ctrl+S — settings: a master-detail pane for providers (keys in the vault, OAuth sign-in, custom OpenAI-compatible endpoints), appearance, agents, skills, hooks, and MCP servers.
• Ctrl+T — the theme picker, with live preview as you move through the list.

Sub-agents

When a turn delegates with agent_spawn, launch returns a receipt immediately and the parent can continue independent work. Each child run appears as a collapsible sub-agent item in the timeline, nested under the turn that spawned it — its own prompt, tool calls, and final summary remain independently foldable in browse mode. Use agent_status for a non-blocking snapshot and agent_await to join when the parent needs the result. A coordinator fanning out to read-only explore workers reads as a tidy tree rather than a wall of interleaved output; conflicting workspace writes are refused instead of racing.

Keybinding reference

Key	Action
Enter	submit the prompt
Shift+Enter / Ctrl+J	newline in the composer
↑ / ↓	browse input history (in the composer)
Tab	enter timeline browse mode
v / y	select transcript lines / copy selection in browse mode
Esc	stop the running turn / leave browse / close an overlay
Shift+Tab	toggle plan ⇄ build mode
Ctrl+L	expand / collapse the context dashboard
Ctrl+W	working set (changed files & turns)
Ctrl+F	file viewer (Files / Skills / Agents / Hooks)
Ctrl+E	model & provider picker
Ctrl+S	settings
Ctrl+T	theme picker
Ctrl+P	plan pane
Ctrl+K	agents & skills catalog
Ctrl+G	key help
Ctrl+Q	clear context (with confirm)
Ctrl+I	inspector
Ctrl+C	quit

Slash commands work in the composer too: /clear resets the conversation, /help opens the key help. Press Ctrl+G any time for the full, context-aware list.

Launch flags

Flag	Effect
(none)	interactive TUI starting on the intro screen
--continue	resume the previous session in this workspace
--agent <name>	start with a named agent profile (agents/<name>.md)
--env <path>	load a .env file before reading config
--headless	run one task to completion with no TUI, recording the result to state.db
--prompt-text <s> / --prompt-file <p>	the task prompt for --headless
--max-iter <n>	override the iteration cap for --headless (0 = config default)
